UV Protection Spinnaker Low Aspect High Aspect Storm One Design Classic
Solartex
#Solution dyed polyester
Introduction →
Product Specifications Download
Solartex contains 4 products for plenty of applications
User-friendly with excellent Anti-UV performance
Excellent abrasion resistance

The main purpose of Solartex ST series is to provide user-friendly and high-quality fabric with little damage to the environment and the best cost performance ratio.

Various colours, great Anti-UV performance and customized possibility, which all make Solartex ST series your best companion whether outdoors or at sea.

Check Introduction for more detailed information and recommendation.

Product Weight (g/m2) Width (cm) Warp x Fill Data Sheet
ST170 170 147 300D X 300D -
ST240PSA 240 142 300D X 300D -
ST250 250 147 600D X 300D -
ST300 300 147 600D X 600D -
End applications：Cover, Leech and foot protection, Lazy bag, Cradle, Roller furling cover, Winter cover, Bow cover, Console cover, Sprayhood, Windshield cover, and so on.
Natural White
Pacific Blue
Blue
Linen
Navy Blue
Anthracite
Black
Light Grey
Cadet Grey
Charcoal
Beige Grey
Red
Ruby
Forest Green
Comparison
End Application Solartex ST series WeatherMax Sunbrella
Leech and Foot Protection ST170, 170 g/m2 WeatherMax LT, 220 g/m2 Sunbrella Furling, 195 g/m2
Sunbrella, 300 g/m2
Bow cover, Curtain, Sail cover, Roller-furling cover, Wndscreen cover, etc. ST250, 250 g/m2 WeatherMax 80, 271 g/m2 Sunbrella Plus, 320 g/m
Lazy bag, Sprayhood, Small bimini top, Winter cover, etc. ST300, 300 g/m2 WeatherMax 80, 271 g/m2 Sunbrella Plus, 320 g/m
Solartex vs WeatherMax vs Sunbrella
Product Solartex ST series WeatherMax Sunbrella
100% Solution Dyed Polyester 100% Solution Dyed Polyester Solution Dyed Acrylic
Environmentally-friendly Solution dyed (Green) Solution dyed Toxic chemicals are discharged during production
Cost-perfomance ratio High Medium Low
Weights 3 Weights 2 Weights Varies
Pressure Sensitive Adhesive (PSA) Available in various colours Available Available in 2 colours
Physical properties performance Stronger tearing and tensile Stronger tearing and tensile Weaker tearing and tensile
if all at the same weight (the strongest yarn)
if all to be used for same application, like
Leech & Foot protection		 Lightest
(ST170)		 Heavy
(220 g/m2)		 Heavy
(195 g/m2)
Finish Water-repellent & Water-proof
Anti-UV		 Water-repellent Water-repellent
Warranty 5 years 3 or 10 years limited warranty 7 years
×
Solution dyed polyester

Solution dyed polyester outperforms other fabrics in terms of Anti-UV rays, colour fastness, GREEN nature, etc., and allows long-time exposure to the sun.

Fansuby Sailcloth’s UV protection have excellent Anti-UV performance (UPF 50+) and color fading resistance (over 4.0 out of 5 Grade), which makes Fansuby Sailcloth’s Solartex ST series a great alternative for either Sunbrella or WeatherMax on the market.

  • Marine Applications
  • ・ST170 (170 g/m2) – Leech and Foot protection
  • ・ST250 (250 g/m2) – Bow cover, Roller-furling cover, Sail cover, Curtain, Windscreen cover, etc.
  • ・ST300 (300 g/m2) – Sail cover, Lazy bag, Winter cover, Small Bimini top, Flybridge enclosure, Cradle, Mooring cover, etc.
  • If you don’t have sewing machines, ST240PSA is the best choice for you:
  • ・ST240PSA：ST170 with PSA in the back.

PSA (Pressure Sensitive Adhesive): insignia type of UV protection, produced with lightweight release paper, is ideal for sails which require more reinforcements and extra protection.

If you are making covers, we would recommend ST250/ST300 with water-proof coating, the best resolution for Marine products that require water proof.

Let our Solartex ST series be your best shield to protect whatever you value most from sunlight.
